Designing comply with request of the latest environment and certificate
Designing comply with request of the latest environment and certificate
► High power density：100mm×30mm×20mm(including baseboard)
► Damp proofing
► LED Display
► Leakage Current: Less than 0.5mA
► Altitude:5000m
► No damage with input 300VAC at 10s
► Ventilation cooling
|
Model |
Item |
N3.3 |
N4.2 |
N4.6 |
N5 |
N7.5 |
N12 |
||
|
Output |
DC Voltage |
3.3V |
4.2V |
4.6V |
5V |
7.5V |
12V |
||
|
Current Range |
0-12A |
0-12A |
0-12A |
0-12A |
0-8A |
0-5A |
|||
|
Rated Power |
40W |
50W |
55W |
60W |
60W |
60W |
|||
|
Ripple & Noise |
100mV |
100mV |
100mV |
100mV |
100mV |
100mV |
|||
|
Voltage Tolerance |
±3% |
±3% |
±3% |
±3% |
±3% |
±3% |
|||
|
Input |
Voltage Range |
90-264V |
90-264V |
90-264V |
90-264V |
90-264V |
90-264V |
||
|
Efficiency |
83% |
84% |
84% |
85% |
86% |
86% |
|||
|
Inrush Current |
100A |
100A |
100A |
100A |
100A |
100A |
|||
|
PF Factor |
≥0.5 |
≥0.5 |
≥0.5 |
≥0.5 |
≥0.5 |
≥0.5 |
|||
|
Protection |
Over Load |
Over current120%~180%,can auto-recover remove abnormal |
|||||||
|
Over Voltage |
Can auto-recover after remove abnormal. |
||||||||
|
Environment |
Operating Temperature |
-20℃-70℃ |
|||||||
|
Storage Temperature |
-40℃-85℃ |
||||||||
|
Certificates |
|||||||||
|
Remark |
All spec. will be tested at input 220V,rate loading,25 ℃ ambient temperature if without special notice |
||||||||
|
User need to refer temperature drop curve and input voltage drop curve |
|||||||||
