Designing comply with request of the latest environment and certificate
►High power density:127mm×81mm×40mm
►Damp proofing
►LED Display
►Leakage Current: Less than 0.5mA
►Altitude:5000m
►No damage with input 300VAC at 10s
►Enforce cooling
►Complied with EMC standards:GB9254，EN55022A CLASSB
|
Model |
Item |
P200 |
P150 |
||
|
Output |
DC Voltage |
150-200V |
75-150V |
||
|
Current Range |
1A |
1.5A |
|||
|
Rated Power |
200W |
200W |
|||
|
Current Ripple |
±10% |
±10% |
|||
|
Current Tolerance |
±5% |
±5% |
|||
|
Input |
Voltage Range |
90-264V |
90-264V |
||
|
Efficiency |
88% |
88% |
|||
|
Inrush Current |
100A |
100A |
|||
|
PF Factor |
≥0.95 |
≥0.95 |
|||
|
Protection |
Over Load |
Over current 120%~180%,can auto-recover remove abnormal |
|||
|
Over Voltage |
Above 220V,LATCH OFF |
||||
|
Over Temperature |
Auto-recover |
||||
|
Environment |
Operating Temperature |
-40℃-70℃ |
|||
|
Storage Temperature |
-40℃-85℃ |
||||
|
Remark |
All spec. will be tested at input 220V,rate loading,25 ℃ ambient temperature if without special notice |
||||
|
User need to refer temperature drop curve and input voltage drop curve |
|||||
|
Support PWM dim frequency 150-600Hz, support strobe flash 0-50Hz. |
|||||
